FRONT bucket elevator conveyor belt patent series -- Part 3

Type: Company News 201

Patent No.: 201820852420.6

Patent introduction: Bucket elevator conveyor belt is strip structure, which needs to be assembled with clamps to connect and fix the two ends of the belt into a ring to realize continuous operation driven by roller.

Advantages of patented products:

1, The upper part of the fixture is provided with an outer cover, which is an open structure at the lower part, and can be buckled on the upper part of the fixture for convenient installation;


2, The utility model can form an integral fixation and sealing protection for the end of the tape, and prolong the service life;


3, The two external clamps are symmetrically provided with positioning grooves, and the outer cover is provided with a pressing part matching with the positioning groove, which can increase the clamping strength of the upper part of the external clamp to the tape, reduce the weight of the external clamp, and overcome the impact of centrifugal force during the operation of the bucket elevator;


4, The whole structure is stable and has better connection strength; the self weight is light and easy to use.


Product application:

Our products are used well in Shougang sintering plant, Tongli cement and many other enterprises. Our customers evaluate that the fixture provided by our company is easy to install, operate and more safe and stable.
